Soft Seal Butterfly Valve-D341X-16

Product Introduction

The center plate butterfly valve with flange connection combines some advantages of eccentric flange butterfly valve and clamp butterfly valve, filling a gap between eccentric flange butterfly valve and clamp butterfly valve.

Product features

The bidirectional sealing performance is excellent, and the torque value is small. The machining performance of the parts is good.

The flow characteristics tend to be linear, and the regulation performance is good.

The flange connection is easy to install, and can be installed vertically or horizontally.

The diversity of sealing materials is available for users to choose from.

The valve can be used as a vent valve at the pipe end, with reliable performance

The valve seat sealing ring is organically combined with the valve body to provide a longer service life for the valve.

Strong anti erosion performance, suitable for harsh working conditions, can be used for medium interception and regulation.

Main performance parameters

Nominal pressure: DN50-DN1400

Nominal diameter: PN10

Test pressure: Shell 1.5mpa Seal 1.1mpa

Applicable temperature: -15 ° C -+110 ° C

Applicable media: fresh water, sewage, seawater, air, food, various oils, etc

Drive mode: handle, worm gear, pneumatic or electric device

Nominal pressure: DN50-DN1400

Nominal diameter: PN16

Test pressure: Shell 2.4mpa Seal 1.76mpa

Applicable temperature: -15 ° C -+110 ° C

Applicable media: fresh water, sewage, seawater, air, food, various oils, etc

Drive mode: handle, worm gear, pneumatic or electric device

Main component materials
